Huawei Campus Fixed Switch

S110-24T2SR

Basic Information
Part Number	98012196
Model	S110-24T2SR
Description	S110-24T2SR (24*10/100/1000BASE-T ports, 2*GE SFP ports, AC power)
Technical Specifications
Chassis material	Metal
Height [mm]	43.6 mm
Depth [mm]	160.0 mm
Wide [mm]	442.0 mm
Chassis height [U]	1
Weight with packaging [kg(lb)]	2.3 (5.07)
Weight without packaging [kg(lb)]	1.8 (3.97)
Maximum power consumption [W]	17
Typical power consumption [W]	16
Heat dissipation mode	Natural heat dissipation
Maximum heat dissipation [BTU/hour]	58
Typical heat dissipation [BTU/hour]	54.6
Power supply mode	AC built-in
Input voltage range [V]	AC input: 90 V AC to 264 V AC; 45 Hz to 65 Hz
Rated input voltage [V]	AC input: 100–240 V AC; 50/60 Hz
Maximum input current [A]	0.8 A
Number of power slots	0
Number of card slots	0
Memory	-
Flash memory	-
Redundant power supply	Not supported
Types of fans	None
Noise at normal temperature (acoustic power) [dB(A)]	Noise-free (no fans), < 30
Noise at normal temperature (acoustic pressure) [dB(A)]	Noise-free (no fans), < 20
Airflow direction	-
Storage temperature [°C(°F)]	–40°C to +70°C (–40°F to +158°F)
Long-term operating temperature [°C(°F)]	0°C to 40°C (32°F to 104°F) at an altitude of 0-1800 m (0-5906 ft.)
Restriction on the operating temperature variation rate [°C(°F)]	When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).
Long-term operating relative humidity [RH]	5% RH to 95% RH (non-condensing)
Storage altitude [m(ft.)]	0-5000 m (0-16404 ft.)
Long-term operating altitude [m(ft.)]	0–5000 m (0–16404 ft.)
MTBF [year]	76.10
MTTR [hour]	2
Availability	> 0.99999
Maximum number of physical ports on the entire device	26
Maximum number of 100GE ports	0
Maximum number of 40GE ports	0
Maximum number of 25GE ports	0
Maximum number of 10GE ports	0
Maximum number of GE ports	26
Maximum number of FE ports	26
Downlink ports	24 x 10/100/1000BASE-T ports
Uplink ports	2 x GE SFP ports
USB	Not supported
Console port	Not supported
Eth Management port	Not supported
Working mode	- Standard mode - Port isolation - Uplink aggregation - Flow control disabling
MAC address entry	8K
Service port surge protection [kV]	Common mode: ±1 kV
Power supply surge protection	Differential mode: ±6 kV; common mode: ±6 kV
RPS input	Not supported
PoE	Not supported
